AIE-PX11/12/21/22-A2
• 支持NVIDIA Jetson AGX Orin™ 32GB/64GB模块
• 具有2/4组IEEE 802.3af GbE PSE连接埠
• 具有一组GbE、一组10GbE
• 具有一组B-Key、一组E-Key、一组M-Key插槽
• 宽输入电压设计：9至36VDC
• 作业温度-25°C ~ +55°C
• 无风扇设计
 |
产品介绍
| • 八倍AI算力实现低延迟AI推论 |
| NVIDIA Jetson AGX Orin计算核心提供最高275 TOPS算力，是NVIDIA Jetson AGX Xavier™ 32GB计算模块的八倍以上。此系统内置2048 NVIDIA CUDA®cores及64 Tensor Cores，能在边缘端实现伺服器等级、低延迟的AI推论。 |
| • 完善的M.2扩展、PSE及区域网路连接埠 |
| AIE-PX11/12/21/22作为具有高扩展性的系统，内置一组支持LTE/5G的M.2 B-Key、一组支持Wifi/蓝牙的M.2 E-Key、一组支持存储硬体扩展的M.2 M-Key。在网路方面，该系统搭载的2或4组的PSE连接埠能够支持2或4组POE cameras，加上一组10GbE连接埠，提供了最高100亿位元/秒的高速数据传输功能，比传统GbE标准高了10倍。 |
| • 宽输入电压和和无风扇设计 适用于智能城市和智能农业 |
|
为了满足智能城市和智能农业等各种应用的需求，高成本效益的维护和高可靠性至关重要。因此，AIE-PX11/12/21/22特别设计了无风扇和静音机制、能在-25°C至55°C的作业温度范围内运行。此外，支持9至36 VDC的广输入电源范围，提供弹性的电源供应选择。 |
产品规格
| Model Number | AIE-PX11-1-A2 | AIE-PX12-1-A2 | AIE-PX21-1-A2 | AIE-PX22-1-A2 |
| Module Compatibility | NVIDIA Jetson AGX Orin 32GB | NVIDIA Jetson AGX Orin 64GB | ||
| AI Performance | 200 TOPS | 275 TOPS | ||
| GPU | 1792-core NVIDIA Ampere GPU with 56 Tensor Cores | 2048-core NVIDIA Ampere GPU with 64 Tensor Cores | ||
| CPU | 8-core Arm® Cortex® -A78AE v8.2 64-bit CPU 2MB L2 + 4MB L3 | 12-core Arm® Cortex® -A78AE v8.2 64-bit CPU 3MB L2 + 6MB L3 | ||
| Memory | 32GB 256-bit LPDDR5 204.8 GB/s | 64GB 256-bit LPDDR5 204.8 GB/s | ||
| Storage | 64GB eMMC 5.1 | |||
| Display | 1 x HDMI 2.0 Type A | |||
| TPM | TPM v2.0 (optional) | |||
| LAN | 1 x RJ-45 1GbE, 1 x RJ-45 10GbE | |||
| PoE Interface | 2 x RJ-45 GbE PSE | 4 x RJ-45 GbE PSE | 2 x RJ-45 GbE PSE | 4 x RJ-45 GbE PSE |
| IEEE 802.3af compliant, power output 15W / port *PSE Port 1 & Port 2 support IEEE 802.3at compliant; Total PSE ports support up to 60W |
||||
| USB | 1 x USB 2.0 (DB-15), 2 x USB 3.2 Gen1 Type-A, 1 x USB 3.2 Gen2 Type-C, 1 x USB OTG Type-C | |||
| I/O Interfaces | 2 x I2C 1 x SPI 5 x GPIO 2 x UART 1 x RS-232 1 x RS-422/485 (2-in-1) 2 x CAN 2.0b (isolated; CAN FD supported) |
|||
| Expansion | 1 x M.2 B-Key 3042/3052 (LTE/4G/5G) 1 x M.2 E-Key 2230 (Wi-Fi/BT) 1 x M.2 M-Key 2280 (supports NVMe; PCIe Gen4 x4) 1 x micro-SD card holder 1 x micro-SIM card holder 1 x OOB (out-of-band, optional) |
|||
| MISC. Function | 1 x Power button, 1 x Recovery button, 1 x Reset button | |||
| Power Input/Connector | DC-in 9–36 VDC, 4-pin DC jack power connector | |||
| Power Consumption | Idle: 7.5 W Full Loading: 109* W |
Idle: 12 W Full Loading: 150* W |
||
| *For more test condition inf ormation, please ref er to user manual | ||||
| Dimension (WxDxH) | 270 x 195 x 80 mm (10.63 x 7.67 x 3.15 in) | |||
| Mounting | Wall Mount (optional) / Din Rail (optional) | |||
| Net Weight | 4.3 kg (9.48 lb) | |||
| Vibration | 1 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis | |||
| Shock | 10 G, IEC 60068-2-27, half sine, 11 ms duration | |||
| Temperature | Operating Temperature: -25°C ~ +55°C (-13°F ~ +131°F) with 0.5 m/s air flow Storage Temperature: -40°C ~ +85°C (-40°F ~ +185°F) |
|||
| Humidity | 95% @ 40°C (104°F) (non-condensing) | |||
| Software Support | Linux (supports NVIDIA JetPack™ 6.2 and above) | |||
| Certification | CE, FCC Class A, UKCA | |||
*Product specifications are subject to change without prior notice
产品规格
订购信息
| Model Number | Description |
|---|---|
|
AIE-PX11-1-A2 |
AGX Orin 32GB, 1 x HDMI, 1 x GbE, 1 x 10GbE, 2 x PoE, 3 x USB, B/E/M Key, 9 to 36 VDC input, -25°C ~ +55°C |
|
AIE-PX12-1-A2 |
AGX Orin 32GB, 1 x HDMI, 1 x GbE, 1 x 10GbE, 4 x PoE, 3 x USB, B/E/M Key, 9 to 36 VDC input, -25°C ~+55°C |
|
AIE-PX21-1-A2 |
AGX Orin 64GB, 1 x HDMI, 1 x GbE, 1 x 10GbE, 2 x PoE, 3 x USB, B/E/M Key, 9 to 36 VDC input, -25°C ~ +55°C |
|
AIE-PX22-1-A2 |
AGX Orin 64GB, 1 x HDMI, 1 x GbE, 1 x 10GbE, 4 x PoE, 3 x USB, B/E/M Key, 9 to 36 VDC input, -25°C ~ +55°C |
