AIE-KX11/12/21/22

• 搭载NVIDIA^® Jetson AGX Orin™ 32GB/64GB计算核心

• 最高可达275 TOPS的AI算力

• 宽输入电压设计：9至36VDC

• 具有一组B-Key、一组E-Key、一组M-Key插槽

• 具有一组GbE、一组10GbE、2/4组IEEE 802.3af GbE PSE连接端口

• 支持Innodisk频外远端管理模块

• 运行温度：-25°C至+70°C

Datasheet

产品介绍
产品规格
产品规格
订购信息
相关下载

产品介绍

•八倍AI算力实现低延迟AI推论

NVIDIA Jetson AGX Orin计算核心提供最高275 TOPS算力，是NVIDIA® Jetson AGX Xavier™ 32GB计算模块的八倍以上。此系统内建2048 NVIDIA® CUDA® cores及64 Tensor Cores，能在边缘端实现服务器等级、低延迟的AI推论。

•完善的M.2扩展及区域网络连接端口

AIE-KX11/12/21/22作为具有扩展性的系统，内建一组支持LTE/5G的M.2 B-Key、一组支持Wifi/蓝牙的M.2 E-Key、一组支持储存硬件扩展的M.2 M-Key。在网络方面，该平台搭载的2或4组的PSE连接端口能够支持2或4组POE cameras，加上一组10GbE连接端口，提供了最高100亿位元/秒的高速数据传输功能，比传统GbE标准高了10倍。

•宽输入电压及宽运行温度设计，适用多种嵌入式应用

为了能适用于多种嵌入式应用，特别是如智能工厂、智能城市、智能交通等涉及严苛环境的场域，AIE-KX11/12/21/22能够在-25°C至+70°C内正常运行，并支持9至36VDC的宽输入电压。

产品规格

Model Number	AIE-KX11-1-A2	AIE-KX12-1-A2	AIE-KX21-1-A2	AIE-KX22-1-A2
Module Compatibility	NVIDIA Jetson AGX Orin 32GB		NVIDIA Jetson AGX Orin 64GB
AI Performance	200 TOPS		275 TOPS
GPU	1792-core NVIDIA Ampere GPU with 56 Tensor Cores		2048-core NVIDIA Ampere GPU with 64 Tensor Cores
CPU	8-core NVIDIA Arm® Cortex A78AE v8.2 64-bit CPU 2MB L2 + 4MB L3		12-core NVIDIA Arm® Cortex A78AE v8.2 64-bit CPU 3MB L2 + 6MB L3
Memory	32 GB 256-bit LPDDR5 204.8 GB/s		64GB 256-bit LPDDR5 204.8 GB/s
Storage	64GB eMMC 5.1
Display	1 x HDMI 2.0 Type A
Audio	Line-out / Line-in / Mic (optional with daughter board)
TPM	TPM v2.0 (optional)
LAN	1 x RJ-45 1GbE port 1 x RJ-45 10GbE port
PoE Interface	2 x RJ-45 GbE PSE	4 x RJ-45 GbE PSE	2 x RJ-45 GbE PSE	4 x RJ-45 GbE PSE
	*IEEE 802.3af compliant, 15 W per port; PSE ports 1 & 2 support IEEE 802.3at; total PSE power up to 60 W
USB	2 x USB 3.2 Gen 1 Type-A 1 x USB 3.2 Gen 2 Type-C 1 x USB 2.0 (DB-15) 1 x USB 2.0 OTG Type-C
I/O Interfaces	5 x GPIO 2 x I²C 2 x UART 2 x CAN 2.0b (Isolated, CAN FD supported) 1 x SPI 1 x RS-232 1 x RS-422/485 (2-in-1)
Expansion	1 x M.2 B-Key 3042/3052 (LTE/4G/5G) 1 x M.2 E-Key 2230 (Wi-Fi/BT) 1 x M.2 M-Key 2280 (NVMe, PCIe Gen 4 x4) 1 x microSD card slot 1 x micro SIM card slot 1 x OOB (out-of-band, opt ional)
MISC. Function	1 x Power button, 1 x Recovery button, 1 x Reset button
Power Input / Connector	DC-in 9–36 VDC, 4-pin DC jack power connector
Power Consumption	Idle: 14.3 W Full Loading: 115.8* W		Idle: 14.8 W Full Loading: 136.8* W
	*For more test condition information, please refer to user manual
Dimension (WxDxH)	220 x 170 x 79 mm (8.66 x 6.69 x 3.11 in)
Mounting	Wall mount (optional) / Din rail (optional)
Net Weight	1.852 kg (4 lb)
Vibration	1 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis
Shock	10 G, IEC 60068-2-27, half sine, 11 ms duration
Temperature	Operat ing Temp.: -25°C – 70°C (-13°F – 158°F) with 0.5 m/s airflow Super Mode: No thermal throttling under full CPU and GPU load at 65°C Storage Temp.: -40°C – 85°C (-40°F – 185°F)
Humidity	95% @ 40°C (104°F) (non-condensing)
Software Support	Linux (supports NVIDIA® Jetpack 6.2 and above)
Certification	CE, FCC Class A, UKCA

产品规格

Written in preliminary datasheet

Model Number

AIE-KX11/12/21/22

加入比较开始比较

订购信息

Model Number	Description
AIE-KX11-1-A2	AGX ORIN 32GB + carrier board + FAN + chassis + power adaptor + US power cord with 2 PSE ports, -25°C to +70°C
AIE-KX12-1-A2	AGX ORIN 32GB + carrier board + FAN + chassis + power adaptor + US power cord with 4 PSE ports, -25°C to +70°C
AIE-KX21-1-A2	AGX ORIN 64GB + carrier board + FAN + chassis + power adaptor + US power cord with 2 PSE ports, -25°C to +70°C
AIE-KX22-1-A2	AGX ORIN 64GB + carrier board + FAN + chassis + power adaptor + US power cord with 4 PSE ports , -25°C to +70°C
